Microchip Technology APTM100TA35SCTPG

Name: APTM100TA35SCTPG
Brand: Microchip Technology
SKU: APTM100TA35SCTPG
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Part No.:: APTM100TA35SCTPG

Manufacturer:: Microchip Technology

Category:: Transistors - FETs, MOSFETs - Arrays

Package:: Module

Datasheet:: APTM100TA35SCTPG.pdf

Description:: MOSFET 6N-CH 1000V 22A SP6P

Quantity:: RFQ

Payment:

Shipping:

Product details

Packaging:
Bulk
Series:
POWER MOS 7®
ProductStatus:
Active
FETType:
6 N-Channel (3-Phase Bridge)
FETFeature:
Standard
DraintoSourceVoltage(Vdss):
1000V (1kV)
Current-ContinuousDrain(Id)@25°C:
22A
RdsOn(Max)@IdVgs:
420mOhm @ 11A, 10V
Vgs(th)(Max)@Id:
5V @ 2.5mA
GateCharge(Qg)(Max)@Vgs:
186nC @ 10V
InputCapacitance(Ciss)(Max)@Vds:
5200pF @ 25V
Power-Max:
390W
OperatingTemperature:
-40°C ~ 150°C (TJ)
MountingType:
Chassis Mount
Category:
Transistors - FETs, MOSFETs - Arrays
Datasheet:

APTM100TA35SCTPG.pdf

Part Number	APTM50AM38FTG	APTM100H45SCTG	APTM120H29FG	APTM100TA35SCTPG
Manufacturer	Microchip Technology	Microchip Technology	Microchip Technology	Microchip Technology
Packaging	Bulk	Bulk	Bulk	Bulk
Series	POWER MOS 7®	POWER MOS 7®	POWER MOS 7®	POWER MOS 7®
ProductStatus	Active	Active	Active	Active
FETType	6 N-Channel (3-Phase Bridge)	6 N-Channel (3-Phase Bridge)	6 N-Channel (3-Phase Bridge)	6 N-Channel (3-Phase Bridge)
FETFeature	Standard	Standard	Standard	Standard
DraintoSourceVoltage(Vdss)	1000V (1kV)	1000V (1kV)	1000V (1kV)	1000V (1kV)
Current-ContinuousDrain(Id)@25°C	22A	22A	22A	22A
RdsOn(Max)@IdVgs	420mOhm @ 11A, 10V	420mOhm @ 11A, 10V	420mOhm @ 11A, 10V	420mOhm @ 11A, 10V
Vgs(th)(Max)@Id	5V @ 2.5mA	5V @ 2.5mA	5V @ 2.5mA	5V @ 2.5mA
GateCharge(Qg)(Max)@Vgs	186nC @ 10V	186nC @ 10V	186nC @ 10V	186nC @ 10V
InputCapacitance(Ciss)(Max)@Vds	5200pF @ 25V	5200pF @ 25V	5200pF @ 25V	5200pF @ 25V
Power-Max	390W	390W	390W	390W
OperatingTemperature	-40°C ~ 150°C (TJ)	-40°C ~ 150°C (TJ)	-40°C ~ 150°C (TJ)	-40°C ~ 150°C (TJ)
MountingType	Chassis Mount	Chassis Mount	Chassis Mount	Chassis Mount
