Panasonic Electronic Components ECE-A1HN101U

Name: ECE-A1HN101U
Brand: Panasonic Electronic Components
SKU: ECE-A1HN101U
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Part No.:: ECE-A1HN101U

Manufacturer:: Panasonic Electronic Components

Category:: Aluminum Electrolytic Capacitors

Package:

Datasheet:: ECE-A1HN101U.pdf

Description:: CAP ALUM 100UF 20% 50V RADIAL

Quantity:: RFQ

Payment:

Shipping:

Product details

Packaging:
Bulk
Series:
SU
ProductStatus:
Active
Capacitance:
100 µF
Tolerance:
±20%
Voltage-Rated:
50 V
ESR(EquivalentSeriesResistance):
-
Lifetime@Temp:
2000 Hrs @ 85°C
OperatingTemperature:
-40°C ~ 85°C
Polarization:
Bi-Polar
Ratings:
-
Applications:
General Purpose
RippleCurrent@LowFrequency:
250 mA @ 120 Hz
RippleCurrent@HighFrequency:
425 mA @ 10 kHz
Impedance:
-
LeadSpacing:
0.197 (5.00mm)
Size/Dimension:
0.394 Dia (10.00mm)
Height-Seated(Max):
0.787 (20.00mm)
SurfaceMountLandSize:
-
MountingType:
Through Hole
Category:
Aluminum Electrolytic Capacitors
Datasheet:

ECE-A1HN101U.pdf

Part Number	ECE-A1HN101U	ECE-A1HN100UB	ECE-A1HN4R7UB	ECE-A1AN101XB	ECE-A1EN101UB
Manufacturer	Panasonic Electronic Components	Panasonic Electronic Components	Panasonic Electronic Components	Panasonic Electronic Components	Panasonic Electronic Components
Packaging	Bulk	Bulk	Bulk	Bulk	Bulk
Series	SU	SU	SU	SU	SU
ProductStatus	Active	Active	Active	Active	Active
Capacitance	100 µF	100 µF	100 µF	100 µF	100 µF
Tolerance	±20%	±20%	±20%	±20%	±20%
Voltage-Rated	50 V	50 V	50 V	50 V	50 V
ESR(EquivalentSeriesResistance)	-	-	-	-	-
Lifetime@Temp	2000 Hrs @ 85°C	2000 Hrs @ 85°C	2000 Hrs @ 85°C	2000 Hrs @ 85°C	2000 Hrs @ 85°C
OperatingTemperature	-40°C ~ 85°C	-40°C ~ 85°C	-40°C ~ 85°C	-40°C ~ 85°C	-40°C ~ 85°C
Polarization	Bi-Polar	Bi-Polar	Bi-Polar	Bi-Polar	Bi-Polar
Ratings	-	-	-	-	-
Applications	General Purpose	General Purpose	General Purpose	General Purpose	General Purpose
RippleCurrent@LowFrequency	250 mA @ 120 Hz	250 mA @ 120 Hz	250 mA @ 120 Hz	250 mA @ 120 Hz	250 mA @ 120 Hz
RippleCurrent@HighFrequency	425 mA @ 10 kHz	425 mA @ 10 kHz	425 mA @ 10 kHz	425 mA @ 10 kHz	425 mA @ 10 kHz
Impedance	-	-	-	-	-
LeadSpacing	0.197 (5.00mm)	0.197 (5.00mm)	0.197 (5.00mm)	0.197 (5.00mm)	0.197 (5.00mm)
Size/Dimension	0.394 Dia (10.00mm)	0.394 Dia (10.00mm)	0.394 Dia (10.00mm)	0.394 Dia (10.00mm)	0.394 Dia (10.00mm)
Height-Seated(Max)	0.787 (20.00mm)	0.787 (20.00mm)	0.787 (20.00mm)	0.787 (20.00mm)	0.787 (20.00mm)
SurfaceMountLandSize	-	-	-	-	-
MountingType	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole
