Littelfuse Inc. MG12300D-BN2MM

Name: MG12300D-BN2MM
Brand: Littelfuse Inc.
SKU: MG12300D-BN2MM
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Part No.:: MG12300D-BN2MM

Manufacturer:: Littelfuse Inc.

Category:: Transistors - IGBTs - Modules

Package:: D-3 Module

Datasheet:: MG12300D-BN2MM.pdf

Description:: IGBT MODULE 1200V 480A 1450W D3

Quantity:: RFQ

Payment:

Shipping:

Product details

Packaging:
Bulk
Series:
-
ProductStatus:
Obsolete
IGBTType:
-
Configuration:
Half Bridge
Voltage-CollectorEmitterBreakdown(Max):
1200 V
Current-Collector(Ic)(Max):
480 A
Power-Max:
1450 W
Vce(on)(Max)@VgeIc:
1.7V @ 15V, 300A
Current-CollectorCutoff(Max):
1 mA
InputCapacitance(Cies)@Vce:
21 nF @ 25 V
Input:
Standard
NTCThermistor:
No
OperatingTemperature:
-40°C ~ 125°C (TJ)
MountingType:
Chassis Mount
Category:
Transistors - IGBTs - Modules
Datasheet:

MG12300D-BN2MM.pdf

Part Number	MG12300D-BN2MM	MG12200D-BN2MM	MG06200S-BN4MM	MG12100W-XN2MM	MG12100D-BA1MM
Manufacturer	Littelfuse Inc.	Littelfuse Inc.	Littelfuse Inc.	Littelfuse Inc.	Littelfuse Inc.
Packaging	Bulk	Bulk	Bulk	Bulk	Bulk
Series	-	-	-	-	-
ProductStatus	Obsolete	Obsolete	Obsolete	Obsolete	Obsolete
IGBTType	-	-	-	-	-
Configuration	Half Bridge	Half Bridge	Half Bridge	Half Bridge	Half Bridge
Voltage-CollectorEmitterBreakdown(Max)	1200 V	1200 V	1200 V	1200 V	1200 V
Current-Collector(Ic)(Max)	480 A	480 A	480 A	480 A	480 A
Power-Max	1450 W	1450 W	1450 W	1450 W	1450 W
Vce(on)(Max)@VgeIc	1.7V @ 15V, 300A	1.7V @ 15V, 300A	1.7V @ 15V, 300A	1.7V @ 15V, 300A	1.7V @ 15V, 300A
Current-CollectorCutoff(Max)	1 mA	1 mA	1 mA	1 mA	1 mA
InputCapacitance(Cies)@Vce	21 nF @ 25 V	21 nF @ 25 V	21 nF @ 25 V	21 nF @ 25 V	21 nF @ 25 V
Input	Standard	Standard	Standard	Standard	Standard
NTCThermistor	No	No	No	No	No
OperatingTemperature	-40°C ~ 125°C (TJ)	-40°C ~ 125°C (TJ)	-40°C ~ 125°C (TJ)	-40°C ~ 125°C (TJ)	-40°C ~ 125°C (TJ)
MountingType	Chassis Mount	Chassis Mount	Chassis Mount	Chassis Mount	Chassis Mount
