Texas Instruments PTB78560CAH

Name: PTB78560CAH
Brand: Texas Instruments
SKU: PTB78560CAH
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Part No.:: PTB78560CAH

Manufacturer:: Texas Instruments

Category:: DC DC Converters

Package:: 11-DIP Module

Datasheet:: PTB78560CAH.pdf

Description:: DC DC CONVERTER 9-13.2V 30W

Quantity:: RFQ

Payment:

Shipping:

Product details

Package/Case:
11-DIP Module
Packaging:
Tray
Series:
PTB78560 (30W)
ProductStatus:
Not For New Designs
Type:
Isolated Module
NumberofOutputs:
1
Voltage-Input(Min):
18V
Voltage-Input(Max):
60V
Voltage-Output1:
9 ~ 13.2V
Voltage-Output2:
-
Voltage-Output3:
-
Voltage-Output4:
-
Current-Output(Max):
2.5A
Power(Watts):
30 W
Voltage-Isolation:
1.5 kV
Applications:
ITE (Commercial)
Features:
-
OperatingTemperature:
-40°C ~ 85°C
Efficiency:
88%
MountingType:
Through Hole
Size/Dimension:
2.05 L x 1.05 W x 0.39 H (52.1mm x 26.7mm x 10.0mm)
ControlFeatures:
ApprovalAgency:
Category:
DC DC Converters
Datasheet:

PTB78560CAH.pdf

Part Number	PTB78560CAH	PTB78560AAH	PTB78560CAZ	PTB78560BAH	PTB78560AAS
Manufacturer	Texas Instruments	Texas Instruments	Texas Instruments	Texas Instruments	Texas Instruments
Package/Case	11-DIP Module	11-DIP Module	11-DIP Module	11-DIP Module	11-DIP Module
Packaging	Tray	Tray	Tray	Tray	Tray
Series	PTB78560 (30W)	PTB78560 (30W)	PTB78560 (30W)	PTB78560 (30W)	PTB78560 (30W)
ProductStatus	Not For New Designs	Not For New Designs	Not For New Designs	Not For New Designs	Not For New Designs
Type	Isolated Module	Isolated Module	Isolated Module	Isolated Module	Isolated Module
NumberofOutputs	1	1	1	1	1
Voltage-Input(Min)	18V	18V	18V	18V	18V
Voltage-Input(Max)	60V	60V	60V	60V	60V
Voltage-Output1	9 ~ 13.2V	9 ~ 13.2V	9 ~ 13.2V	9 ~ 13.2V	9 ~ 13.2V
Voltage-Output2	-	-	-	-	-
Voltage-Output3	-	-	-	-	-
Voltage-Output4	-	-	-	-	-
Current-Output(Max)	2.5A	2.5A	2.5A	2.5A	2.5A
Power(Watts)	30 W	30 W	30 W	30 W	30 W
Voltage-Isolation	1.5 kV	1.5 kV	1.5 kV	1.5 kV	1.5 kV
Applications	ITE (Commercial)	ITE (Commercial)	ITE (Commercial)	ITE (Commercial)	ITE (Commercial)
Features	-	-	-	-	-
OperatingTemperature	-40°C ~ 85°C	-40°C ~ 85°C	-40°C ~ 85°C	-40°C ~ 85°C	-40°C ~ 85°C
Efficiency	88%	88%	88%	88%	88%
MountingType	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole
Size/Dimension	2.05 L x 1.05 W x 0.39 H (52.1mm x 26.7mm x 10.0mm)	2.05 L x 1.05 W x 0.39 H (52.1mm x 26.7mm x 10.0mm)	2.05 L x 1.05 W x 0.39 H (52.1mm x 26.7mm x 10.0mm)	2.05 L x 1.05 W x 0.39 H (52.1mm x 26.7mm x 10.0mm)	2.05 L x 1.05 W x 0.39 H (52.1mm x 26.7mm x 10.0mm)
ControlFeatures
ApprovalAgency
