STMicroelectronics STS5NF60L

Name: STS5NF60L
Brand: STMicroelectronics
SKU: STS5NF60L
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Part No.:: STS5NF60L

Manufacturer:: STMicroelectronics

Category:: Transistors - FETs, MOSFETs - Single

Package:: 8-SOIC

Datasheet:: STS5NF60L.pdf

Description:: MOSFET N-CH 60V 5A 8SO

Quantity:: RFQ

Payment:

Shipping:

Product details

Packaging:
Tape & Reel (TR),Cut Tape (CT)
Series:
STripFET™
ProductStatus:
Active
FETType:
N-Channel
Technology:
MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss):
60 V
Current-ContinuousDrain(Id)@25°C:
5A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn):
4.5V, 10V
RdsOn(Max)@IdVgs:
55mOhm @ 2.5A, 10V
Vgs(th)(Max)@Id:
2.5V @ 250µA
GateCharge(Qg)(Max)@Vgs:
17 nC @ 5 V
Vgs(Max):
±20V
InputCapacitance(Ciss)(Max)@Vds:
1250 pF @ 25 V
FETFeature:
-
PowerDissipation(Max):
2.5W (Tc)
OperatingTemperature:
150°C (TJ)
MountingType:
Surface Mount
Category:
Transistors - FETs, MOSFETs - Single
Datasheet:

STS5NF60L.pdf

Part Number	STS5NF60L	STW40NF20	STU6NF10	STL55NH3LL	STK820
Manufacturer	STMicroelectronics	STMicroelectronics	STMicroelectronics	STMicroelectronics	STMicroelectronics
Packaging	Tape & Reel (TR),Cut Tape (CT)	Tape & Reel (TR),Cut Tape (CT)	Tape & Reel (TR),Cut Tape (CT)	Tape & Reel (TR),Cut Tape (CT)	Tape & Reel (TR),Cut Tape (CT)
Series	STripFET™	STripFET™	STripFET™	STripFET™	STripFET™
ProductStatus	Active	Active	Active	Active	Active
FETType	N-Channel	N-Channel	N-Channel	N-Channel	N-Channel
Technology	MOSFET (Metal Oxide)	MOSFET (Metal Oxide)	MOSFET (Metal Oxide)	MOSFET (Metal Oxide)	MOSFET (Metal Oxide)
DraintoSourceVoltage(Vdss)	60 V	60 V	60 V	60 V	60 V
Current-ContinuousDrain(Id)@25°C	5A (Tc)	5A (Tc)	5A (Tc)	5A (Tc)	5A (Tc)
DriveVoltage(MaxRdsOnMinRdsOn)	4.5V, 10V	4.5V, 10V	4.5V, 10V	4.5V, 10V	4.5V, 10V
RdsOn(Max)@IdVgs	55mOhm @ 2.5A, 10V	55mOhm @ 2.5A, 10V	55mOhm @ 2.5A, 10V	55mOhm @ 2.5A, 10V	55mOhm @ 2.5A, 10V
Vgs(th)(Max)@Id	2.5V @ 250µA	2.5V @ 250µA	2.5V @ 250µA	2.5V @ 250µA	2.5V @ 250µA
GateCharge(Qg)(Max)@Vgs	17 nC @ 5 V	17 nC @ 5 V	17 nC @ 5 V	17 nC @ 5 V	17 nC @ 5 V
Vgs(Max)	±20V	±20V	±20V	±20V	±20V
InputCapacitance(Ciss)(Max)@Vds	1250 pF @ 25 V	1250 pF @ 25 V	1250 pF @ 25 V	1250 pF @ 25 V	1250 pF @ 25 V
FETFeature	-	-	-	-	-
PowerDissipation(Max)	2.5W (Tc)	2.5W (Tc)	2.5W (Tc)	2.5W (Tc)	2.5W (Tc)
OperatingTemperature	150°C (TJ)	150°C (TJ)	150°C (TJ)	150°C (TJ)	150°C (TJ)
MountingType	Surface Mount	Surface Mount	Surface Mount	Surface Mount	Surface Mount
